Libera BPM AMP

Libera BPM AMP is a low-noise RF amplifier designed to enhance beam position monitor signals prior to BPM signal processing. By providing stable and precise gain, it improves measurement accuracy, resolution, and reliability, particularly in low beam charge operating conditions.

Product Description

Benefits:

  • Improved signal integrity
    Increases BPM signal amplitude prior to processing, helping preserve measurement quality and stability.
  • Enhanced measurement accuracy and resolution
    Low-noise amplification improves beam position measurement precision, especially under demanding operating conditions.
  • Optimized for low beam charge operation
    Helps maintain reliable BPM performance even when beam signals are weak.
  • Dedicated versions for different beam modes
    Separate CW and pulsed variants allow optimization for continuous-wave, macropulse, and single-bunch accelerator operation.
  • Integrated filtering for pulsed applications
    The pulsed version includes optimized bandpass filtering for short-duration pulsed signals, improving signal selectivity and processing performance.
Technical specifications of the Libera BPM AMP
CW versionPulsed version
General product codeLAMBLAMB
Gain ~ 25 dB~ 16.5 dB
P1dB17 dBm13 dBm
Bandwith< 850 MHz494.5 MHz - 504.1 MHz
NF< 3.4 dB @ 750 MHz< 7.5 dB @ 500 MHz
Power consumption12 VA12 VA
Supply voltage85-264 VAC, 47-63 Hz85-264 VAC, 47-63 Hz
Dimensions43.8 x 210 x 173 mm43.8 x 210 x 173 mm
Weight1,65 kg1,65 kg
